CY62147EV18LL-55BVXI IC SRAM 4MBIT PARALLEL 48VFBGA Infineon Technologies

Name: CY62147EV18LL55BVXI IC SRAM 4MBIT PARALLEL 48VFBGA Infineon Technologies
Brand: Infineon Technologies
Price: 1 USD

Brand Name : Infineon Technologies

Model Number : CY62147EV18LL-55BVXI

MOQ : 1

Price : Based on current price

Payment Terms : T/T

Supply Ability : In stock

Delivery Time : 3-5 work days

Packaging Details : anti-static bag & cardboard box

Memory Type : Volatile

Memory Format : SRAM

Technology : SRAM - Asynchronous

Memory Size : 4Mbit

Memory Organization : 256K x 16

Memory Interface : Parallel

Clock Frequency : -

Write Cycle Time - Word, Page : 55ns

Access Time : 55 ns

Voltage - Supply : 1.65V ~ 2.25V

Operating Temperature : -40°C ~ 85°C (TA)

Mounting Type : Surface Mount

Package / Case : 48-VFBGA

Supplier Device Package : 48-VFBGA (6x8)

Contact Now

Product Details

Functional Description

The CY62147CV25/30/33 are high-performance CMOS static RAMs organized as 256K words by 16 bits. These devices feature advanced circuit design to provide ultra-low active current. This is ideal for providing More Battery Life™ (MoBL™) in portable applications such as cellular telephones. The devices also have an automatic power-down feature that significantly reduces power consumption by 80% when addresses are not toggling.

Features

• High Speed
— 55 ns and 70 ns availability
• Voltage range:
— CY62147CV25: 2.2V–2.7V
— CY62147CV30: 2.7V–3.3V
— CY62147CV33: 3.0V–3.6V
• Pin Compatible with CY62147V
• Ultra-low active power
— Typical active current: 1.5 mA @ f = 1 MHz
— Typical active current: 5.5 mA @ f = fmax (70 ns speed)
• Low standby power
• Easy memory expansion with CE and OE features
• Automatic power-down when deselected
• CMOS for optimum speed/power

Specifications

Attribute	Attribute Value
Manufacturer	Cypress Semiconductor
Product Category	Memory ICs
Series	MoBL®
Type	Asynchronous
Packaging	Tray Alternate Packaging
Unit-Weight	0.007873 oz
Mounting-Style	SMD/SMT
Tradename	MoBL
Package-Case	48-VFBGA
Operating-Temperature	-40°C ~ 85°C (TA)
Interface	Parallel
Voltage-Supply	1.65 V ~ 2.25 V
Supplier-Device-Package	48-VFBGA (6x8)
Memory Capacity	4M (256K x 16)
Memory-Type	SRAM - Asynchronous
Speed	55ns
Data-Rate	SDR
Access-Time	55 ns
Format-Memory	RAM
Maximum Operating Temperature	+ 85 C
Operating temperature range	- 40 C
Interface-Type	Parallel
Organization	256 k x 16
Supply-Current-Max	20 mA
Supply-Voltage-Max	2.25 V
Supply-Voltage-Min	1.65 V
Package-Case	VFBGA-48

Form,Package,Functional compatible component

Manufacturer Part#	Description	Manufacturer	Compare
CY62147EV18LL-55BVX Memory	Standard SRAM, 256KX16, 55ns, CMOS, PBGA48, 6 X 8 MM, 1 MM HEIGHT, LEAD FREE, VFBGA-48	Cypress Semiconductor	CY62147EV18LL-55BVXI vs CY62147EV18LL-55BVX

Descriptions

SRAM - Asynchronous Memory IC 4Mb (256K x 16) Parallel 55ns 48-VFBGA (6x8)

SRAM Chip Async Single 1.8V 4M-Bit 256K x 16 55ns 48-Pin VFBGA Tray

SRAM 4Mb 1.8V 55ns 256K x 16 LP SRAM
